Parameters
Machine size(L*W*H):8600*1500*2500(4m)
Working width:4m
M/C gauge:1/5+1/5(both sides),1/4+1/4(both sides)
Main structure:cast frame and six position foot screw ensure machine stability
Total power ref.:45KW(4m)
Mechanical speed:600 RPM
Pile height:2.5-9mm
Stitch rate:25-60 stitches/10cm
Primary back roller loading:cylinder automatic control
Primary back fabric feeding:double servo motor control
Gauge parts:both Groz and China made available.
Adjustable bed plate:flexible manual control.
Standard power cabinet and operation cabinet with 12.5"touch screen
Industrial computer with latest windows system
Puller roller:servo motor control
Sliding:double needle bar sliding,max.Max.15 needles on left or right
Yarn feeding:servo control 2+2 or 3+3 or 4+4
Application
This model of Graphic tufting machine is specially designed for carpet tile and wall to wall carpet, with good stability and high output.
Shipping terms
1. 100% T/T in advance.
2. 30% T/T in advance, and 70% against copy of Bill of Lading (B/L).
3. 100% by Irrevocable Letter of Credit at sight.
4. 100% by D/P at sight（The specific payment terms can be confirmed according to the circumstances of both parties.）.
Packing and shipping
1. Standard export packing is provided for this machine.
2. tufting machine requires 1x40HQ or 2x40HQ containers for loading,special
requirements needs to be negotiated specifically.
3. Before shipment, we will confirm with the customer the test video of the machine operating properly.
WARRANTY:
1. Warrant for Electrical parts: 1 year, customer bear courier/airfreight charge
2. Warranty for Control Panel: 1 year
3. Mechanical parts (not including consuming parts) 1 year
FAQ
Q 1: Payment terms capacity?
A 1: T/T, L/C, Western Union etc.
Q 2: Trade terms?
A 2: In according with Incoterms 2010, normally with EXW, FOB shanghai, CFR, CIP, CIF and DDU.
Q 3: Validity of quotation?
A 3: Within 30 days.
Q 4: Modes of shipment?
A 4: By sea or railway.
Q 5: Warranty?
A 5: One year. Will offer after sell service in whole life of machine use under compensation after one year.
Q 6: Installation and training?
A 6: There is technical and installation support in India. Other countries, paid overseas engineering service provided.
